1 ton 1.5 ton 3m New three-wheeled electric forklift with small turning radius for warehouses

Taizhou Custom Forklift Co.,Ltd
Contact Now

1 ton 1.5 ton 3m New three-wheeled electric forklift with small turning radius for warehouses

Applicable Industries : hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising C

Condition : New

Place of Origin : Jiangsu, China

Terrain Adaptability : Indoor Flooring

Brand Name : KAD

Power Souce : AC Motor

Fork Length : 1070mm

Warranty : 1 Year

Product Name : Electric Forklift

Power type : Electric Power

Loading Capacity : 1000kg

Weight : 1600kg

Brand : KAD

Load Center : 500mm

Tyres : Solid core tire

Showroom Location : UAE, None

Machinery Test Report : Provided

Video outgoing-inspection : Provided

Warranty of core components : 1 Year

Core Components : Pressure vessel, motor, Bearing, Gear, Pump, Gearbox, Engine

Min. Lifting Height : 55mm

Overall Dimensions : 2970*1020*2100

Weight (KG) : 1600 kg

Price : CN¥37,790.48/sets 1-9 sets

Contact Now

1 ton 1.5 ton 3m New three-wheeled electric forklift with small turning radius for warehouses
1 ton 1.5 ton 3m New three-wheeled electric forklift with small turning radius for warehouses
Model
CPD1030
CPD1530
Load capacity (kg)
1000
1500
Lift height (mm)
3000
3000
Load centre (mm)
500
500
Fork size (mm)
1070*100*40
1070*100*40
Ground Clearance (mm)
55/150
55/150
Tyre Type
Solid Tyres
Solid Tyres
Control Way
Steering Wheel
Steering Wheel
Speed Regulation Way
Stepless Speed Regulation
Stepless Speed Regulation
Protection Guard Height(mm)
2000
2000
Mast Tilt Angle (Front/Rear)(°)
3.0/6.0
3.0/6.0
The Min.Turning Radius(mm)
1750
1750
Driving Speed with Full Load(km/h)
6.5
6.5
Maximum Gradient with full load(°)
3/5
3/5
Battery(V/Ah)
48/140
48/140
Reference Working Time(h)
4/6
4/6
Driving Motor(kw)
3
3
Lifting Motor(kw)
3
3
Tyre Size (Front/ Rear)(mm)
350/300
350/300
Overall Dimension(L*W*H)(mm)
2970*1020*2100
3100*1020*2100
Weight(kg)
1600
1700
Increased height each tonnage(mm)
1600/2000/2500/3000/3500
Max height(mm)
2100/1600/1850/2100/2350
1 ton 1.5 ton 3m New three-wheeled electric forklift with small turning radius for warehouses
1 ton 1.5 ton 3m New three-wheeled electric forklift with small turning radius for warehouses
1 ton 1.5 ton 3m New three-wheeled electric forklift with small turning radius for warehouses
1 ton 1.5 ton 3m New three-wheeled electric forklift with small turning radius for warehouses

Main Features

1. Medium duty material handling, stacking and loading/unloading. 2. Designed for narrow aisles. 3. Single-sided and double-sided pallets can be used. 4. The drive motor and drive axle adopt the unique gear parallel shaft design arrangement, which improves the transmission efficiency and reduces the transmission noise. 5. Spacious operating space and adjustable seat provide a comfortable working environment for the operator. 6. Large-capacity battery ensures the stability and reliability for long time use.

1 ton 1.5 ton 3m New three-wheeled electric forklift with small turning radius for warehouses
1 ton 1.5 ton 3m New three-wheeled electric forklift with small turning radius for warehouses
1 ton 1.5 ton 3m New three-wheeled electric forklift with small turning radius for warehouses
1 ton 1.5 ton 3m New three-wheeled electric forklift with small turning radius for warehouses
Related Products
1 ton 1.5 ton 3m New three-wheeled electric forklift with small turning radius for warehouses
1 ton 1.5 ton 3m New three-wheeled electric forklift with small turning radius for warehouses
1 ton 1.5 ton 3m New three-wheeled electric forklift with small turning radius for warehouses
1 ton 1.5 ton 3m New three-wheeled electric forklift with small turning radius for warehouses
Q1. What is your terms of packing? A: Generally, we pack our goods in paper package and Iron pallet. We can pack the goods in your branded boxes after getting your authorization letters. Q2. What is your terms of payment? A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance. Or As negotiated Q3. What is your terms of delivery? A: EXW, FOB, CFR, CIF, DDU. Q4. How about your delivery time? A: Generally, it will take 5 to 30 days after receiving your deposit. The specific delivery time depends on the items and the quantity of your order. Q5. Do you test all your goods before delivery? A: Yes, we have 100% test before delivery Q6: How do you make our business long-term and good relationship? 1. We keep good quality and competitive price to ensure our customers benefit ; 2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
